    Glow Plug - CH203 CHAMPION
    Glow Plug - CH203 CHAMPION
    Glow Plug - CH203 CHAMPION
    Glow Plug - CH203 CHAMPION
    Glow Plug - CH203 CHAMPION
    Glow Plug - CH203 CHAMPION
    Glow Plug - CH203 CHAMPION
    Glow Plug - CH203 CHAMPION
    Part Number: CH203

    Glow Plug - CH203 CHAMPION

    0 Reviews
    Brand: CHAMPION
    €7.67
    In Stock (5)
    • Glow Plug Design: after-glow capable, Pencil-type Glow Plug
    • Spanner Size: 10 mm
    • Fitting Depth [mm]: 33
    • Packaging width [cm]: 2.7
    • Thread Size: M10x1,0
    • Packaging height [cm]: 2.3
    • Packing Type: Box
    • Fuel Mixture Formation: Common Rail (CR)
    • Voltage [V]: 11
    • Failure Moment [Nm]: 35
    • Diameter [mm]: 5
    • Tightening torque from [Nm]: 15
    • Connector type: 4 mm PIN
    • Current Strength [A]: 15
    • Cone Pitch: 63
    • Overall Length [mm]: 106.5
    • Tightening torque to [Nm]: 20
    • Packaging length [cm]: 14.2
    • EAN: 5010874500235
    Safety and product information:
    Safe payment options
    We only work with the most secure payment systems
    Product return within 30 days
    We do our very best to keep our customers happy
    We ship worldwide
    High quality car parts delivered to your doorstep
    Product compatibility verification
    We verify the compatibility between the ordered products and your vehicle

    Technical Data

    Voltage [V] 11
    Connector type 4 mm PIN
    Cone Pitch 63
    Diameter [mm] 5
    Thread Size M10x1,0
    Overall Length [mm] 106,5
    Fuel Mixture Formation Common Rail (CR)
    Spanner Size 10 mm
    Rated Current [A] 15
    Glow Plug Design after-glow capable
    Glow Plug Design Pencil-type Glow Plug
    Packing Type Box
    Fitting Depth [mm] 33
    Failure Moment [Nm] 35
    Tightening torque from [Nm] 15
    Tightening torque to [Nm] 20
    Packaging length [cm] 14,2
    Packaging width [cm] 2,7
    Packaging height [cm] 2,3

    • 320 d, Engine M47 D20 (204D1), 2.0, 100kW, 1998 - 2001
    • 330 d, Engine M57 D30 (306D1), 3.0, 135kW, 1999 - 2005
    • 330 xd, Engine M57 D30 (306D1), 3.0, 135kW, 2000 - 2003
    • 318 d, Engine M47 D20 (204D1), 2.0, 85kW, 2001 - 2003
    • 320 d, Engine M47 D20 (204D1), 2.0, 95kW, 1998 - 2001

    • 730 d, Engine M57 D30 (306D1), 3.0, 135kW, 1998 - 2000
    • 730 d, Engine M57 D30 (306D1), 3.0, 142kW, 2000 - 2001

    • 530 d, Engine M57 D30 (306D1), 3.0, 135kW, 1998 - 2000
    • 520 d, Engine M47 D20 (204D1), 2.0, 100kW, 2000 - 2003
    • 525 d, Engine M57 D25 (256D1), 2.0, 120kW, 2000 - 2003
    • 530 d, Engine M57 D30 (306D1), 3.0, 142kW, 1998 - 2003

    • 530 d, Engine M57 D30 (306D1), 3.0, 135kW, 1998 - 2000
    • 520 d, Engine M47 D20 (204D1), 2.0, 100kW, 2000 - 2003
    • 525 d, Engine M57 D25 (256D1), 2.0, 120kW, 2000 - 2004
    • 530 d, Engine M57 D30 (306D1), 3.0, 142kW, 2000 - 2004

    • 320 d, Engine M47 D20 (204D1), 2.0, 100kW, 2000 - 2001
    • 330 d, Engine M57 D30 (306D1), 3.0, 135kW, 1999 - 2005
    • 330 xd, Engine M57 D30 (306D1), 3.0, 135kW, 2000 - 2003
    • 318 d, Engine M47 D20 (204D1), 2.0, 85kW, 2002 - 2003

    • 3.0 d, Engine M57 D30 (306D1), 3.0, 135kW, 2001 - 2003

    • 2.0 CDT, Engine 204D2, 2.0, 85kW, 1999 - 2005
    • 2.0 CDTi, Engine 204D2, 2.0, 96kW, 2003 - 2005

    • 2.0 CDT, Engine M 47 R, 2.0, 85kW, 2001 - 2005
    • 2.0 CDTi, Engine 204D2, 2.0, 96kW, 2003 - 2005

    • 2.0 Td4 4x4, Engine M 47, 2.0, 82kW, 2000 - 2006
    • 2.0 Td4 4x4, Engine 204D3, 2.0, 80kW, 2001 - 2006

    • 3.0 D 4x4, Engine 306D1, 3.0, 130kW, 2002 - 2012

    • 2.0 TD4 4x4, Engine 204D3, 2.0, 82kW, 2000 - 2006

    • 2.5 DTI (F69, M69, P69), Engine Y 25 TD, 2.0, 110kW, 2001 - 2003
    • 2.5 DTI (F69, M69, P69), Engine Y 25 DT, 2.0, 110kW, 2001 - 2003

    • 2.5 DTI (F35, M35, P35), Engine Y 25 TD, 2.0, 110kW, 2001 - 2003
    • 2.5 DTI (F35, M35, P35), Engine Y 25 DT, 2.0, 110kW, 2001 - 2003

    • 2.0 CDTi, Engine 204D2, 2.0, 96kW, 2002 - 2005
    • 2.0 CDTi, Engine 204D2, 2.0, 85kW, 2002 - 2003

    • 2.0 CDTi, Engine 204D2, 2.0, 96kW, 2002 - 2005
    • 2.0 CDTi, Engine 204D2, 2.0, 85kW, 2002 - 2005
