| Electrode Gap [mm] | 0,9 |
|---|---|
| Connector type | SAE |
| Thread Size | M14x1.25 |
| Spanner Size | 16 mm |
| Quality/ Grade | Cu-core GE |
| Packing Type | Box |
| Spark Plug | 1 - Earthed Electrode |
| Spark Plug | with gasket seat |
| Spark Plug | Copper Centre Electrode |
| Thread Length [mm] | 26,5 |
| Technical Information Number | REC9YCL |
|---|---|
| Spark Position [mm] | 3 |
| Tightening torque from [Nm] | 20 |
| Tightening torque to [Nm] | 30 |
| Packaging length [cm] | 8,85 |
| Packaging width [cm] | 2,6 |
| Packaging height [cm] | 2,35 |
| Resistance from [kOhm] | 3 |
| Resistance to [kOhm] | 9 |
| Projection [mm] | 1,5 |
