| Voltage [V] | 24 |
|---|---|
| Rated Power [kW] | 4 |
| Number of mounting bores | 3 |
| Number of threaded holes | 0 |
| Number of Teeth | 11 |
| Clamp | 50 |
| Clamp | 30 |
| Flange Diameter [mm] | 89 |
| Rotation Direction | Clockwise rotation |
| Pinion Rest Position [mm] | 28 |
| Starter Type | Self-supporting |
|---|---|
| Bore Diameter [mm] | 10,5 |
| Bore Diameter 2 [mm] | 10,5 |
| Bore Ø 3 [mm] | 10,5 |
| Length [mm] | 317 |
| Position/Degree | links |
| Mounting Angle [degrees] | 30 |
| Jaw opening angle measurement [Degree] | 20 |
| Mounting bore angle measurement [degree] | 30 |
|
|
