Car Parts Online — ELART
Select your vehicle
Compatible with: CITROËN (C5, C8, JUMPER), PEUGEOT (406, 407, 607, 807, BOXER)
| Exchange Part | |
|---|---|
| Voltage [V] | 12 |
| Rated Power [kW] | 1,8 |
| Number of mounting bores | 0 |
| Number of threaded holes | 3 |
| Number of Teeth | 11 |
| Number of Teeth | 10 |
| Clamp | 30,50 |
| Flange Diameter [mm] | 66 |
| Rotation Direction | Clockwise rotation |
| Pinion Rest Position [mm] | -5 |
|---|---|
| Starter Type | Self-supporting |
| Thread Size | M10x1.5 |
| Thread Size 1 | M10x1.5 |
| Thread Size 2 | M10x1.5 |
| Length [mm] | 265 |
| Position/Degree | links |
| Mounting Angle [degrees] | 56 |
| Jaw opening angle measurement [Degree] | 40 |
| Mounting bore angle measurement [degree] | 56 |
|
