Compatible with: AUDI (A1, A3, Q2), SEAT (ALTEA, ATECA, IBIZA, LEON, TOLEDO), SKODA (FABIA, KAROQ, OCTAVIA, RAPID, ROOMSTER, SUPERB, YETI), VW (BEETLE, CC, GOLF, JETTA, PASSAT, POLO, SCIROCCO, TOURAN)
| Voltage [V] | 12 |
|---|---|
| Rated Power [kW] | 1,2 |
| Number of mounting bores | 2 |
| Number of threaded holes | 0 |
| Number of Teeth | 11 |
| Clamp | 30,50 |
| Flange Diameter [mm] | 79 |
| Rotation Direction | Anticlockwise rotation |
| Pinion Rest Position [mm] | 62,5 |
|---|---|
| Bore Diameter [mm] | 12,6 |
| Bore Diameter 2 [mm] | 12,6 |
| Length [mm] | 212 |
| Position/Degree | rechts |
| Mounting Angle [degrees] | 47 |
| Mounting bore angle measurement [degree] | 47 |
|
|
