Compatible with: AUDI (TT), VW (JETTA, NEW, PASSAT, POLO)
| Voltage [V] | 12 |
|---|---|
| Rated Power [kW] | 1,4 |
| Number of mounting bores | 2 |
| Number of threaded holes | 0 |
| Number of Teeth | 10 |
| Clamp | 30,50 |
| Flange Diameter [mm] | 76,2 |
| Rotation Direction | Anticlockwise rotation |
| Pinion Rest Position [mm] | 61,8 |
|---|---|
| Starter Type | Floating pinion |
| Bore Diameter [mm] | 12,6 |
| Bore Diameter 2 [mm] | 12,6 |
| Length [mm] | 235 |
| Position/Degree | links |
| Mounting Angle [degrees] | 47 |
| Mounting bore angle measurement [degree] | 47 |
|
|
