Select your vehicle
Compatible with: BMW (1, 2, 3, 4, 5, 7, X1, X3, X5)
| Voltage [V] | 12 |
|---|---|
| Rated Power [kW] | 2,2 |
| Number of mounting bores | 3 |
| Number of threaded holes | 0 |
| Number of Teeth | 11 |
| Clamp | 30,50 |
| Flange Diameter [mm] | 69 |
| Rotation Direction | Clockwise rotation |
| Pinion Rest Position [mm] | 5,15 |
| Starter Type | Self-supporting |
|---|---|
| Bore Diameter [mm] | 9 |
| Bore Diameter 2 [mm] | 9 |
| Bore Ø 3 [mm] | 9 |
| Length [mm] | 201 |
| Position/Degree | rechts |
| Mounting Angle [degrees] | 51 |
| Jaw opening angle measurement [Degree] | 5 |
| Mounting bore angle measurement [degree] | 51 |
|
|
