Car Parts Online — ELART
Select your vehicle
Compatible with: TOYOTA (DYNA, HIACE, HILUX, LAND)
| Voltage [V] | 12 |
|---|---|
| Rated Power [kW] | 2,7 |
| Number of mounting bores | 2 |
| Number of threaded holes | 1 |
| Number of Teeth | 11 |
| Clamp | 30,50 |
| Flange Diameter [mm] | 82,5 |
| Rotation Direction | Clockwise rotation |
| Pinion Rest Position [mm] | 18,21 |
|---|---|
| Starter Type | Self-supporting |
| Thread Size | M12x1,25 |
| Bore Diameter [mm] | 14 |
| Length [mm] | 260 |
| Position/Degree | rechts |
| Mounting Angle [degrees] | 53 |
| Mounting bore angle measurement [degree] | 53 |
|
|
