Compatible with: OPEL (AGILA, CORSA)
| Production Number | 073067 |
|---|---|
| Cylinder Bore [mm] | 73,4 |
| Piston Clearance [mm] | 0,04 |
| Compression Height [mm] | 24 |
| Length [mm] | 45 |
| Recess Depth 1 [mm] | 0,82 |
| Valve Pocket Depth 1 [mm] | 1,33 |
| Valve Pocket Depth 2 [mm] | 1,35 |
| Recess Diameter [mm] | 52 |
|---|---|
| Component Number | 63179 |
| Component Number | 63182 |
| Component Number | 63185 |
| Standard Size [STD] | |
| Bolt Head Diameter [mm] | 18 |
| Bolt Length [mm] | 51 |
| replace in sets only |
|
63179 |
| Height [mm] | 1,2 |
| Thickness [mm] | 2,95 |
| Cylinder Bore [mm] | 73,4 |
| Surface | Nitrified |
| Surface | Blank |
| Material | Steel |
| Quantity | 1 |
|
63182 |
| Height [mm] | 1,2 |
| Thickness [mm] | 3,1 |
| Cylinder Bore [mm] | 73,4 |
| Surface | Phosphatized |
| Material | Grey Cast Iron |
| Quantity | 1 |
|
63185 |
| Height [mm] | 2 |
| Thickness [mm] | 2,3 |
| Cylinder Bore [mm] | 73,4 |
| Surface | Nitrified |
| Surface | Phosphatized |
| Material | Steel |
| Quantity | 1 |
