Compatible with: FORD (FOCUS, KUGA, TOURNEO, TRANSIT)
| Supplementary Article/Supplementary Info 2 | with bush for piston pin boss |
|---|---|
| Supplementary Article/Supplementary Info 2 | with cooling duct |
| Supplementary Article/Supplementary Info 2 | with piston ring carrier |
| Supplementary Article/Supplementary Info 2 | for keystone connecting rod |
| Recess Depth 1 [mm] | 14,4 |
| Oversize [mm] | 0,5 |
| Compression Height [mm] | 48,4 |
| Height [mm] | 73,2 |
| Cylinder Bore [mm] | 84,51 |
|---|---|
| Bolt Head Diameter [mm] | 30 |
| Recess Diameter [mm] | 48,23 |
| Bolt Length [mm] | 63,65 |
| Valve Pocket Depth 1 [mm] | 0,06 |
| Component Number | 08-452907-00 |
| Machined | with cut-out for oil jet |
| Container Type | Box |
