Compatible with: OPEL (ASTRA, COMBO, CORSA, MERIVA)
| Production Number | 079186 |
|---|---|
| Cylinder Bore [mm] | 79,5 |
| Piston Clearance [mm] | 0,07 |
| Compression Height [mm] | 39,75 |
| Length [mm] | 64,75 |
| Recess Depth 1 [mm] | 14 |
| Recess Diameter [mm] | 41,8 |
| Component Number | 63365 |
|---|---|
| Component Number | 63368 |
| Component Number | 63371 |
| Bolt Head Diameter [mm] | 27 |
| Bolt Length [mm] | 64 |
| Repair Grade | 0,50 |
|
63365 |
| Height [mm] | 2 |
| Thickness [mm] | 2,95 |
| Cylinder Bore [mm] | 79,5 |
| Surface | Chrome ceramic coated |
| Surface | Phosphatized |
| Material | Cast Iron with Ductile Iron |
| Quantity | 1 |
|
63368 |
| Height [mm] | 1,5 |
| Thickness [mm] | 2,8 |
| Cylinder Bore [mm] | 79,5 |
| Surface | Chromed |
| Surface | Phosphatized |
| Material | Grey Cast Iron |
| Quantity | 1 |
|
63371 |
| Height [mm] | 3 |
| Thickness [mm] | 3,39 |
| Cylinder Bore [mm] | 79,5 |
| Surface | Nitrified |
| Surface | Blank |
| Material | Steel |
| Quantity | 1 |
|
