| Production Number | 101059 |
|---|---|
| Cylinder Bore [mm] | 101,5 |
| Piston Clearance [mm] | 0,1 |
| Compression Height [mm] | 55,15 |
| Length [mm] | 90,65 |
| Recess Depth 1 [mm] | 17,51 |
| Recess Diameter [mm] | 64,27 |
| Component Number | 62767 |
|---|---|
| Component Number | 62769 |
| Component Number | 62771 |
| Bolt Head Diameter [mm] | 40 |
| Bolt Length [mm] | 80 |
| Repair Grade | 0,50 |
|
62767 |
| Height [mm] | 2,5 |
| Thickness [mm] | 4,2 |
| Cylinder Bore [mm] | 101,5 |
| Surface | Chrome ceramic coated |
| Surface | Blank |
| Material | Cast Iron with Ductile Iron |
| Quantity | 1 |
|
62769 |
| Height [mm] | 2 |
| Thickness [mm] | 4,2 |
| Cylinder Bore [mm] | 101,5 |
| Surface | Phosphatized |
| Material | Grey Cast Iron |
| Quantity | 1 |
|
62771 |
| Height [mm] | 3 |
| Thickness [mm] | 3,74 |
| Cylinder Bore [mm] | 101,5 |
| Surface | Chromed |
| Surface | Blank |
| Quantity | 1 |
