Compatible with: AUDI (A4, A5, A6, A7, Q5, TT), SKODA (OCTAVIA), VW (GOLF)
| Production Number | 082308 |
|---|---|
| Cylinder Bore [mm] | 82,51 |
| Piston Clearance [mm] | 0,09 |
| Compression Height [mm] | 29,6 |
| Length [mm] | 50,1 |
| Recess Depth 1 [mm] | 4 |
| Valve Pocket Depth 1 [mm] | 3,6 |
| Recess Diameter [mm] | 54,58 |
| Component Number | 66002 |
|---|---|
| Component Number | 66003 |
| Component Number | 66318 |
| Standard Size [STD] | |
| Bolt Head Diameter [mm] | 23 |
| Bolt Length [mm] | 51 |
| Connecting Rod Design | Trapezoidal Connecting Rod |
|
66002 |
| Height [mm] | 1,2 |
| Thickness [mm] | 3,2 |
| Cylinder Bore [mm] | 82,5 |
| Surface | Physical Vapor Deposition (PVD) |
| Surface | Blank |
| Material | Steel |
| Quantity | 1 |
|
66003 |
| Height [mm] | 1,2 |
| Thickness [mm] | 3,2 |
| Cylinder Bore [mm] | 82,5 |
| Surface | Blank |
| Material | Cast Iron with Ductile Iron |
| Quantity | 1 |
|
66318 |
| Height [mm] | 2 |
| Thickness [mm] | 2,4 |
| Cylinder Bore [mm] | 82,5 |
| Surface | Physical Vapor Deposition (PVD) |
| Surface | Blank |
| Material | Steel |
| Quantity | 1 |
