Compatible with: ABARTH (500, 500C, GRANDE), ALFA ROMEO (GIULIETTA, MITO), FIAT (500L, BRAVO, DOBLO, GRANDE, LINEA, PUNTO, TIPO), LANCIA (DELTA)
| Production Number | 072156 |
|---|---|
| Cylinder Bore [mm] | 72,4 |
| Piston Clearance [mm] | 0,04 |
| Compression Height [mm] | 26,8 |
| Length [mm] | 49,7 |
| Recess Depth 1 [mm] | 8,1 |
| Valve Pocket Depth 1 [mm] | 2,6 |
| Valve Pocket Depth 2 [mm] | 1,7 |
| Recess Diameter [mm] | 61,5 |
|---|---|
| Component Number | 66615 |
| Component Number | 66616 |
| Component Number | 66617 |
| Bolt Head Diameter [mm] | 17,97 |
| Bolt Length [mm] | 53 |
| Repair Grade | 0,40 |
|
66615 |
| Height [mm] | 1,2 |
| Thickness [mm] | 2,9 |
| Cylinder Bore [mm] | 72,4 |
| Surface | Chrome ceramic coated |
| Surface | Phosphatized |
| Material | Cast Iron with Ductile Iron |
| Quantity | 1 |
|
66616 |
| Height [mm] | 1,2 |
| Thickness [mm] | 3,15 |
| Cylinder Bore [mm] | 72,4 |
| Surface | Blank |
| Material | Grey Cast Iron |
| Quantity | 1 |
|
66617 |
| Height [mm] | 2 |
| Thickness [mm] | 3,15 |
| Cylinder Bore [mm] | 72,4 |
| Surface | Chromed |
| Surface | Blank |
| Quantity | 1 |
