Select your vehicle
Compatible with: CITROËN (C4, C5, DS4, DS5, GRAND, JUMPER, JUMPY, SPACETOURER), DS (DS), OPEL (GRANDLAND, VIVARO, ZAFIRA), PEUGEOT (3008, 308, 5008, 508, BOXER, EXPERT, TRAVELLER)
| Production Number | 085238 |
|---|---|
| Cylinder Bore [mm] | 85,6 |
| Piston Clearance [mm] | 0,06 |
| Compression Height [mm] | 46,6 |
| Length [mm] | 72,6 |
| Recess Depth 1 [mm] | 12,7 |
| Recess Diameter [mm] | 51,3 |
| Component Number | 66273 |
|---|---|
| Component Number | 66274 |
| Component Number | 66275 |
| Bolt Head Diameter [mm] | 30 |
| Bolt Length [mm] | 68 |
| Repair Grade | 0,60 |
| Connecting Rod Design | Trapezoidal Connecting Rod |
|
66273 |
| Height [mm] | 2 |
| Thickness [mm] | 3,4 |
| Cylinder Bore [mm] | 85,6 |
| Surface | Chrome ceramic coated |
| Surface | Blank |
| Material | Cast Iron with Ductile Iron |
| Quantity | 1 |
|
66274 |
| Height [mm] | 2 |
| Thickness [mm] | 3,3 |
| Cylinder Bore [mm] | 85,6 |
| Surface | Blank |
| Quantity | 1 |
|
66275 |
| Height [mm] | 2 |
| Thickness [mm] | 2,8 |
| Cylinder Bore [mm] | 85,6 |
| Surface | Chromed |
| Surface | Blank |
| Quantity | 1 |
