Compatible with: HYUNDAI (i10, i20), KIA (PICANTO, RIO, STONIC)
| Production Number | 071078 |
|---|---|
| Cylinder Bore [mm] | 71 |
| Piston Clearance [mm] | 0,03 |
| Compression Height [mm] | 24,7 |
| Length [mm] | 42,7 |
| Recess Depth 1 [mm] | 3 |
| Valve Pocket Depth 1 [mm] | 1,9 |
| Valve Pocket Depth 2 [mm] | 1,2 |
| Recess Diameter [mm] | 55,5 |
|---|---|
| Component Number | 100430000 |
| Component Number | 100440000 |
| Component Number | 66145 |
| Standard Size [STD] | |
| Bolt Head Diameter [mm] | 18 |
| Bolt Length [mm] | 48 |
| Connecting Rod Design | Trapezoidal Connecting Rod |
|
66145 |
| Height [mm] | 1 |
| Thickness [mm] | 2,4 |
| Cylinder Bore [mm] | 71 |
| Surface | Chromed |
| Surface | Phosphatized |
| Material | Steel |
| Quantity | 1 |
|
100430000 |
| Height [mm] | 1,2 |
| Thickness [mm] | 2,65 |
| Cylinder Bore [mm] | 71 |
| Surface | Phosphatized |
| Quantity | 1 |
|
100440000 |
| Height [mm] | 2 |
| Thickness [mm] | 2,1 |
| Cylinder Bore [mm] | 71 |
| Surface | Physical Vapor Deposition (PVD) |
| Surface | Phosphatized |
| Material | Steel |
| Quantity | 1 |
|
