Compatible with: FORD (B-MAX, C-MAX, ECOSPORT, FIESTA, FOCUS, GRAND, MONDEO, TOURNEO, TRANSIT)
| Production Number | 072166 |
|---|---|
| Cylinder Bore [mm] | 72,4 |
| Piston Clearance [mm] | 0,04 |
| Compression Height [mm] | 32,9 |
| Length [mm] | 50,9 |
| Recess Depth 1 [mm] | 8,7 |
| Valve Pocket Depth 1 [mm] | 2,9 |
| Valve Pocket Depth 2 [mm] | 2,3 |
| Recess Diameter [mm] | 43 |
|---|---|
| Component Number | 67015 |
| Component Number | 67016 |
| Component Number | 67017 |
| Bolt Head Diameter [mm] | 20 |
| Bolt Length [mm] | 47 |
| Repair Grade | 0,50 |
| Connecting Rod Design | Trapezoidal Connecting Rod |
|
67015 |
| Height [mm] | 1 |
| Thickness [mm] | 2,65 |
| Cylinder Bore [mm] | 72,4 |
| Surface | Physical Vapor Deposition (PVD) |
| Surface | Blank |
| Material | Steel |
| Quantity | 1 |
|
67016 |
| Height [mm] | 1,2 |
| Thickness [mm] | 3 |
| Cylinder Bore [mm] | 72,4 |
| Surface | Phosphatized |
| Quantity | 1 |
|
67017 |
| Height [mm] | 2 |
| Thickness [mm] | 2,55 |
| Cylinder Bore [mm] | 72,4 |
| Surface | Physical Vapor Deposition (PVD) |
| Surface | Phosphatized |
| Material | Steel |
| Quantity | 1 |
|
