Compatible with: AUDI (A3, A4), FORD (GALAXY), SEAT (ALHAMBRA, ALTEA, CORDOBA, IBIZA, LEON, TOLEDO), SKODA (FABIA, OCTAVIA, ROOMSTER, SUPERB), VW (BORA, CADDY, GOLF, JETTA, NEW, PASSAT, POLO, SHARAN, TOURAN)
| Fitting Position | for cylinder 1 |
|---|---|
| Fitting Position | for cylinder 2 |
| Production Number | 07901D-301 |
| Supplementary Article/Supplementary Info 2 | with bush for piston pin boss |
| Supplementary Article/Supplementary Info 2 | with cooling duct |
| Supplementary Article/Supplementary Info 2 | with piston ring carrier |
| Supplementary Article/Supplementary Info 2 | for keystone connecting rod |
| Recess Depth 1 [mm] | 17,2 |
| Piston Clearance [mm] | 0,05 |
| Compression Height [mm] | 45,8 |
| Height [mm] | 68,8 |
|---|---|
| Cylinder Bore [mm] | 79,5 |
| Bolt Head Diameter [mm] | 26 |
| Recess Diameter [mm] | 38 |
| Bolt Length [mm] | 66 |
| Valve Pocket Depth 1 [mm] | 1,1 |
| Component Number | 08-114900-00 |
| Machined | with cut-out for oil jet |
| Standard Size [STD] | |
| Piston Chamber Volume [cm³] | 22,85 |
|
|
