Compatible with: SEAT (CORDOBA, IBIZA), SKODA (FABIA, ROOMSTER), VW (POLO)
| Production Number | 076168 |
|---|---|
| Cylinder Bore [mm] | 77,01 |
| Piston Clearance [mm] | 0,045 |
| Compression Height [mm] | 29,02 |
| Length [mm] | 50,02 |
| Recess Depth 1 [mm] | 4 |
| Valve Pocket Depth 1 [mm] | 1,2 |
| Valve Pocket Depth 2 [mm] | 2,7 |
| Recess Diameter [mm] | 61,4 |
|---|---|
| Component Number | 61758 |
| Component Number | 85529 |
| Component Number | 87612 |
| Bolt Head Diameter [mm] | 17 |
| Bolt Length [mm] | 46 |
| Repair Grade | 0,50 |
|
61758 |
| Height [mm] | 1,2 |
| Thickness [mm] | 2,875 |
| Cylinder Bore [mm] | 77 |
| Surface | Nitrified |
| Material | Steel |
| Quantity | 1 |
|
87612 |
| Height [mm] | 1,5 |
| Thickness [mm] | 3,3 |
| Cylinder Bore [mm] | 77 |
| Surface | Phosphatized |
| Quantity | 1 |
|
85529 |
| Height [mm] | 2,5 |
| Thickness [mm] | 2,83 |
| Cylinder Bore [mm] | 77 |
| Surface | Chromed |
| Quantity | 1 |
|
