| Fastening Type | Screw connection |
|---|---|
| Lamp Type | LED |
| Light Design | LED |
| Voltage [V] | 12 |
| Voltage [V] | 24 |
| Rated Power [W] | 110 |
| Voltage from [V] | 10 |
| Voltage to [V] | 30 |
| Temperature range from [°C] | -40 |
| Temperature range to [°C] | +65 |
| Fitting Position | Front |
| Overall Height [mm] | 77 |
| Length [mm] | 314 |
| Depth [mm] | 73 |
| Height [mm] | 59 |
| Light Function | with high beam (LED) |
| Light Function | with position light (LED) |
| Light Function | with flashing warning signal |
| Number of light functions | 3 |
| Number of LEDs | 66 |
| Light colour | white |
| Light colour | yellow (amber) |
| Cable Length [mm] | 1000 |
| Luminous Flux [lm] | 3800 |
|---|---|
| Theoretical luminous flux [lm] | 6000 |
| Colour Temperature [K] | 5700 |
| Frame Colour | black |
| Shape | Slim |
| Lens Colour | white |
| Housing Colour | black |
| Housing material | Aluminium |
| Diffusing Lens Type | Clear diffusing lens |
| Diffusing Lens Material | PC (Polycarbonate) |
| fulfils EMC/CISPR standard | CISPR 25 Class 3 |
| Registration Type | ECE approved |
| max. light cone range at 1 lux (main light function) [m] | 340 |
| fulfils ECE standard | R65 |
| fulfils ECE standard | R10 |
| fulfils ECE standard | R148 |
| fulfils ECE standard | R149 |
| Protection Type (IP Code) | IP67 |
| Protection Type (IP Code) | IP69K |
| Reference number | 30 |
| Weight [g] | 1400 |
| Assy./disassy. by qualified personnel required! |
|
